BISW060LC-2 Bolondi Compact Tank Head | Dual Nozzle

Product Overview

The Bolondi BISW060LC-2 is a compact, precision-engineered rotary spray jet head designed for high-pressure cleaning in tight or restricted spaces. Operating at 200 bar (2,900 PSI) with a flow rate of approximately 9 L/min (≈2.4 GPM), it delivers strong cleaning impact while maintaining excellent water efficiency. This model is ideal for contractors, municipal sanitation crews, and industrial facilities that require reliable container and tank cleaning in confined environments.

With its dual-nozzle configuration, the BISW060LC-2 provides powerful, targeted jet performance using significantly less water than larger rotary heads—making it cost-effective for frequent daily cleaning cycles.

How It Works

Water-Driven Turbine System

• Powered by an internal Aquamotor turbine.
• Pressurized water drives the turbine blades to rotate the spray head.
• No external motors or electrical connections required.
• Low-maintenance design with fewer moving components.

BISW060LC-2 Dual-Nozzle 360° Spray Pattern

• Two precision nozzles deliver high-impact, focused jets.
• Full 360° internal coverage for complete cleaning.
• Enhanced impact force per jet due to dual-nozzle configuration.
• Minimizes water and chemical usage while ensuring thorough results.

BISW060LC-2 Optimized for Confined Spaces

• Low-clearance body ideal for tight access points.
• Designed for small containers, bins, and vessels.
• Perfect for portable cleaning systems and mobile bin-washing rigs.

Construction & Materials

Durable Alloy Housing

• OT58 Brass / Aluminum Alloy provides a lightweight yet robust frame.
• Resists corrosion, wear, and harsh cleaning chemicals.
• Suitable for hot-water washdown environments.

316 Stainless Steel Components

• Improved heat resistance and long-term durability.
• Enhanced performance in caustic or aggressive cleaning environments.
• Ensures reliable operation under daily industrial use.

Compact Housing Design

• Perfect for narrow openings and limited-space applications.
• Allows deployment in areas where larger rotary heads cannot fit.

Performance Specifications

Operating Parameters

• Maximum Pressure: 2,900 PSI (200 bar)
• Flow Rate: ≈ 9 L/min (≈2.4 GPM)
• Spray Pattern: 360° rotary coverage
• Nozzles: Dual-nozzle configuration
• Rotation Drive: Internal Aquamotor turbine
• Construction: OT58 alloy with stainless steel components
• Applications: Small-to-medium containers, bins, traps, and confined spaces

Applications & Use Cases

Municipal & Public Sanitation

• Wheelie bin cleaning
• Public waste container sanitation
• Small dumpster cleaning

Commercial Waste Management

• Grease trap cleaning
• Food waste and recycling containers
• Daily commercial sanitation cycles

Food & Beverage Processing

• Cleaning small tanks and prep vessels
• Sanitizing internal surfaces of transport bins
• Supporting CIP-style cleaning procedures

Chemical & Pharmaceutical

• Cleaning containers used for caustic materials
• Small batch reactors and portable vessels
• Residue removal in confined processing equipment

Portable & Mobile Cleaning Rigs

• Ideal for mobile bin-washing services
• Fits compact trailer or truck-mounted tank cleaning systems
• Lightweight and easy to deploy repeatedly

Benefits & Differentiators

Compact Power

• High-pressure performance in a small footprint.
• Designed for restricted-access environments.

Dual-Nozzle Efficiency

• Stronger jet impact per nozzle.
• Reduced water and chemical usage.
• Lower operating costs vs. multi-nozzle systems.

360° Cleaning Coverage

• Ensures total internal cleaning, even in irregular geometries.
• Reliable rotation ensures consistent impact on all surfaces.

Self-Powered Turbine Drive

• No external power requirements.
• Simplified installation and maintenance.
• Greater reliability for daily operations.

Durability & Longevity

• Designed for harsh industrial environments.
• Withstands hot water, chemicals, and frequent wash cycles.

Integration & Delivery

Flexible System Compatibility

• Works with CIP systems, mobile rigs, and fixed wash stations.
• Compact size to suit various container and tank types.
• Supports frequent daily cleaning with minimal adjustments.

Build & Lead Times

• Built to order with customizable configurations.
• Standard Lead Time: 8 weeks (air freight)
• Economy Lead Time: 14 weeks (ocean freight)

Compact, efficient, and durable, the Bolondi BISW060LC-2 is the ideal high-pressure cleaning solution for tight spaces where powerful results are required without excessive water or chemical use.
