BIXB030A Bolondi Aquamotor Tank Head | 2900 PSI

BIXB030A – Bolondi Stainless Steel Cleaning Head – Aquamotor Rotary Jet, 2,900 PSI

The Bolondi BIXB030A is a compact stainless steel rotary cleaning head engineered for precision cleaning of small to medium tanks, IBCs, and containers where hygiene, reliability, and controlled spray action are essential. Manufactured in Reggio Emilia, Italy, and part of Bolondi’s Aquamotor series, this model operates entirely on water power—no external motors or electrical drives required. With working pressures up to 2,900 PSI (200 bar), it delivers high-impact cleaning performance within a compact footprint, making it ideal for pharmaceutical, food and beverage, biotech, cosmetics, and specialty chemical applications.

How It Works

Aquamotor Water-Turbine Drive

• Self-powered system uses the force of pressurized water to rotate the internal turbine.
• Eliminates external motors, electrics, or pneumatics.
• Provides consistent, reliable operation in CIP environments.

Controlled 360° Cleaning Pattern

• Spray arms rotate slowly and uniformly for complete internal coverage.
• Ensures no untreated areas or shadow zones inside vessels.
• Ideal for validated cleaning processes requiring repeatability.

High-Impact Jet Action

• Precision-drilled nozzles deliver strong, concentrated cleaning streams.
• Removes tough residues including films, oils, creams, pastes, and viscous build-up.
• Optimized for small and medium vessel geometry.

Construction & Materials

Premium 316L Stainless Steel Build

• Fully constructed from AISI 316L stainless steel.
• Exceptional resistance to chemical cleaners, caustics, and chlorinated solutions.
• Compatible with high-temperature hot-water or steam-assisted CIP cycles.
• Polished sanitary surfaces minimize bacterial adhesion.
• Ideal for regulated industries requiring hygienic design.

Performance Specifications BIXB030A

• Pressure Range: Up to 2,900 PSI (200 bar)
• Drive System: Aquamotor water-turbine
• Rotation Pattern: Full 360° horizontal + vertical
• Flow Range: Optimized for small/medium vessel cleaning
• Design: Compact body for tight openings and restricted access

The slow, deliberate rotation improves cleaning consistency while reducing mechanical wear, maximizing service life and reliability.

Applications

Industries & Use Cases

• Pharmaceutical & Biotech: Fermenters, reactors, mixing tanks.
• Food & Beverage: Small batch tanks, IBCs, dairy vessels, brewing containers.
• Cosmetics & Specialty Chemicals: Oils, creams, resins, viscous product residues.
• Logistics & Distribution: Cleaning IBC totes for reuse.
• General Industry: Pilot tanks, coating drums, process vessels.

Benefits & Differentiators

Performance Advantages

• Compact & Versatile: Ideal for small openings and confined cleaning spaces.
• 360° Coverage: Ensures complete surface treatment with no missed areas.
• High-Impact Jets: Strong cleaning action for demanding residues.

BIXB030A Bolondi Aquamotor Tank Head | 2900 PSI

Operational Benefits

• 316L Stainless Steel: Maximum corrosion resistance and sanitation compliance.
• Water-Powered: No external energy sources required.
• Energy Efficient: Uses only hydraulic energy from the cleaning fluid.
• Validated Cleaning: Suitable for CIP systems requiring documentation.
• Low Maintenance: Minimal moving parts and self-lubricating water motor.

Integration & Delivery

System Compatibility

• Works with CIP systems, portable wash rigs, and automated cleaning loops.
• Designed to match vessel geometry, spray direction, and cleaning requirements.
• Nozzle sizing and configuration available for customization.

BIXB030A Lead Time

• Standard delivery: 8 weeks (air) or 14 weeks (ocean).
• Built to order based on application parameters.

With its Aquamotor drive, compact stainless steel design, and 360° precision coverage, the Bolondi BIXB030A is the ideal solution for validated, hygienic cleaning of small tanks, IBCs, and specialty processing vessels.
