SJV25G27-PAL Pump kit SJV25G27D-F7 | PAL package TPP140, AL1264750

SJV25G27-PAL Pump Kit

Complete 2.5 GPM, 2700 PSI Axial Cam System

The Annovi Reverberi SJV25G27-PAL is a complete, ready-to-install pump kit designed for
light commercial, mobile, and advanced residential pressure washer builds. Centered around the proven
SJV25G27D-F7 axial cam pump, this package delivers 2.5 GPM at 2,700 PSI,
providing reliable cleaning performance for vehicle washing, property maintenance, and small contractor rigs.

Bundled with a TPP140 thermal protector and AL1264750 mounting hardware,
the kit is engineered as a turnkey solution: it arrives pre-filled with oil and includes critical fittings and
hardware so you can mount the pump, connect your plumbing, and get to work with minimal setup time.

SJV25G27-PAL Key Specifications

Pump & System Details

• Flow Rate: 2.5 GPM
• Maximum Pressure: 2,700 PSI
• Pump Type: Axial cam, direct-drive design
• Operating Speed: 3,400 RPM
• Mount Style: F7 gas engine mount (3/4″ SAE J609A flange)
• Thermal Protector: TPP140 (included in kit)
• Mounting Hardware: AL1264750 bracket and hardware (included)
• Crankcase: Factory-filled with break-in oil
• Internal Components: Ceramic plungers, stainless steel valves, heavy-duty seals
• Warranty: 5-year manufacturer’s warranty

What’s Included with SJV25G27-PAL

Kit Components

• SJV25G27D-F7 axial cam pump with F7 gas engine mount pattern
• TPP140 thermal protector to safeguard against bypass overheating
• AL1264750 mounting hardware kit for secure engine attachment
• Garden hose inlet fitting for standard water supply connection
• Factory pre-filled crankcase oil for immediate startup
• Mounting bolts, nuts, and washers as required for installation
• Instruction manual and parts schematic for setup and maintenance reference

How the SJV25G27-PAL Works

Axial Cam Operation & Thermal Protection

The SJV25G27D-F7 pump uses an axial cam piston arrangement, where pistons are aligned with the
drive shaft and actuated by a rotating cam plate. This design has fewer moving parts than a triplex plunger pump,
resulting in a compact, lightweight assembly with reduced maintenance requirements and a smaller footprint—ideal
for portable machines and tight engine compartments.

During normal operation, the pump draws water through the inlet fitting, pressurizes it using the axial pistons, and
delivers consistent output to your high-pressure hose and spray gun. The included TPP140 thermal protector
adds a critical safety layer: when the unit sits in bypass too long and water temperature rises, the protector opens to
relieve hot water and admit cool supply water, helping prevent pump damage caused by overheating.

Benefits

Why This Kit is a Strong Choice

• Turnkey package: pump, thermal protector, hardware, and fittings included in one kit.
• Reliable output: 2.5 GPM at 2,700 PSI for effective light commercial and advanced residential use.
• Built-in protection: TPP140 thermal protector helps prevent overheating during extended bypass.
• Compact and lightweight: axial cam design is ideal for portable and space-limited pressure washers.
• Durable internals: ceramic plungers, stainless steel valves, and quality seals for long service life.
• Quick installation: F7 engine mount and included hardware simplify assembly on compatible gas engines.
• Factory-prepped: pre-filled crankcase oil reduces setup steps and speeds commissioning.

Typical Applications

Where the SJV25G27-PAL Performs Best

• Fleet and vehicle washing for cars, vans, light-duty trucks, and small service vehicles
• Residential and light commercial cleaning of driveways, patios, sidewalks, and decks
• Storefront and building exterior cleaning for small shops and offices
• Mobile contractor wash rigs and portable pressure washer builds
• Agricultural and light equipment rinse-down in shops or barns
• General outdoor property and facility maintenance

Why Choose the SJV25G27-PAL Pump Kit

Practical, Ready-to-Install Solution from Annovi Reverberi

For users who want a hassle-free pump replacement or new build solution, the
SJV25G27-PAL provides a convenient, integrated package. Instead of sourcing a pump, thermal protector,
and mounting hardware separately, this kit bundles them into a matched system that is engineered to work together.

With 2.5 GPM at 2,700 PSI, proven axial cam design, built-in thermal protection, and a
5-year manufacturer’s warranty, this kit is a solid choice for upgrading older equipment or building a
reliable, compact pressure washer for vehicle cleaning, property care, and light commercial work.
