BIFV025-200 Bolondi Rotary Tank Head | 2900 PSI

BIFV025-200 Bolondi Rotary Tank Head | 2900 PSI

The Bolondi BIFV025-200 is a robust stainless steel rotary jet cleaning head, engineered in Reggio Emilia, Italy, for reliable and efficient internal cleaning of medium-to-large enclosed vessels. Rated for 2,900 PSI (200 bar), this model delivers consistent spray force and dependable performance in demanding applications where durability, safety, and repeatability are essential.

Whether integrated into a CIP (Clean-in-Place) system, deployed in mobile wash rigs, or installed in a fixed industrial cleaning loop, the BIFV025-200 excels in applications where tanks, drums, IBCs, and processing vessels must be thoroughly cleaned without manual entry. Its design supports high hygiene standards while reducing downtime and labor costs.

How It Works

The BIFV025-200 operates using a water-powered internal turbine drive that converts hydraulic pressure into smooth, continuous rotation. As high-pressure fluid enters the unit, the turbine powers the spray arms in a controlled 360° rotation, projecting high-velocity jets across all interior surfaces.

Eliminates Blind Spots

• Tank walls and seams
• Internal baffles and welds
• Corners, tight spaces, and irregular contours

Because the drive is fully self-contained, the BIFV025-200 requires no external motors, gears, or power supply—resulting in fewer wear points and a maintenance-light design built for daily industrial service.

Performance Specs (Quick Reference)

• Maximum Pressure: 2,900 PSI (200 bar)
• Spray Coverage: Full 360° rotational jet pattern
• Drive Mechanism: Internal hydraulic water motor (gearless)
• Construction: 100% stainless steel, corrosion-resistant
• Applications: Tanks, IBCs, drums, process vessels, reactors, mixers

Build & Materials (Made to Last)

• All-stainless construction resists wastewater, chemicals, and cleaning agents.
• Precision machining ensures balanced, smooth rotation.
• High-temperature capable for hot water cleaning and sanitization cycles.
• Rugged seals and bearings extend service intervals.
• Compact, versatile dimensions integrate easily into CIP skids or mobile rigs.

Benefits & Differentiators

• Automation-Ready: Fully compatible with CIP cleaning networks.
• Water-Driven Simplicity: No gears, motors, or external drives.
• Hygienic Performance: Delivers consistent, sanitary cleaning cycles.
• Industrial Durability: Built for aggressive, high-duty environments.
• Compact Efficiency: Optimized balance of coverage and cleaning intensity.
• Built to Order: 8 weeks via air freight or 14 weeks via standard cargo.

Industries & Applications

• Food & Beverage: Tanks, mixers, fermenters, syrup vessels.
• Pharmaceutical & Biotech: GMP-compliant stainless steel cleaning.
• Chemical Processing: Removal of films, residues, and deposits.
• Paints & Coatings: Clearing cured pigments and adhesive remnants.
• Agriculture & Sanitation: Cleaning IBCs, wash tanks, mobile units.

Setup, Use & Maintenance

• Connect to a high-pressure pump (up to 2,900 PSI).
• Insert through vessel manway or fixed cleaning port.
• Verify full 360° rotation prior to full cleaning cycle.
• Flush with clean water after chemical or detergent use.
• Inspect seals and turbine bearings periodically; rebuild kits available.

Thanks to its gear-free turbine design, the BIFV025-200 offers low maintenance requirements and long service intervals, even in high-frequency cleaning environments.

What’s Included

• Bolondi BIFV025-200 stainless steel rotary cleaning head
• Standard threaded inlet connection for CIP integration
• Basic operating and care guide

BIFV025-200 Bolondi Rotary Tank Head | 2900 PSI

• Designed for internal vessel cleaning only—use with compatible pressures and fluids.
• Verify chemical compatibility with stainless steel before use.
• Ensure correct pump flow to achieve proper rotation speed and cleaning intensity.
