AR41451 | RTX Pump Mounting Kit, Rail Hardware

AR41451 RTX Hydraulic Motor Mounting Kit | F51 Bell Housing and Flexible Coupling, 1 in. Shaft

The AR41451 is Annovi Reverberi’s F51 mounting kit for driving an RTX series pump with a hydraulic motor. It is a bell housing and flexible coupling that joins the pump to an SAE J744 B 2-bolt or 4-bolt hydraulic motor with a 1 in. (25.4 mm) shaft. The bell housing holds pump and motor in perfect alignment, and the flexible coupling absorbs start-up shock and small misalignment before it reaches the pump bearings.

It turns an RTX pump into a hydraulic-drive unit you can run off a truck, skid steer, excavator or any hydraulic power pack. Choose it over a close-coupled flange when your motor’s shaft does not match the pump directly, or when you want coupling protection on a unit that runs long hours.

Will It Fit My System?

• Pumps: AR RTX series, including the up-to-100 L/min, up-to-150 L/min and 500 bar models.
• Motor mount: SAE J744 B, 2-bolt or 4-bolt flange.
• Motor shaft: 1 in. (25.4 mm). Match the kit to your motor’s shaft before ordering.

Different motor shaft? The RTX kit family covers the common hydraulic motor shafts:

• AR41450 (F50): 22.22 mm (7/8 in.) shaft
• AR43781 (F53): 28.58 mm (1-1/8 in.) shaft
• AR43780 (F52): 15-tooth splined shaft
• AR46091 (F54): 13-tooth splined shaft

Not sure which you need? Text a specialist at (505) 226-6061 with your motor model and we’ll match the kit.

AR41451 Specifications

• Model: AR41451 (F51)
• Type: Bell housing with flexible coupling
• Motor Mount: SAE J744 B101-2 / B101-4
• Motor Shaft: 1 in. (25.4 mm)
• Fits: AR RTX series pumps
• Weight: 12 lbs
• Brand: Annovi Reverberi

Shipping: Usually ships via UPS in 1 to 3 days.
