The AR AL692 mini pressure switch is a compact, precision-engineered control device from
Annovi Reverberi’s AL Series, designed to provide accurate, automatic pressure regulation in high-pressure
cleaning systems. By starting the pump when demand appears and stopping it once target pressure is restored,
the AL692 helps the system run only as needed, conserving energy and reducing wear on seals, valves, motors,
and electrical components.

How the AL692 Controls Pressure

Automatic start/stop logic

Inside the switch, a precision-calibrated diaphragm works with a tuned spring and sealed electrical contacts to
sense changes in system pressure. When pressure falls below the cut-in level, the AL692 closes the circuit and
energizes the pump. As the line recovers to the cut-out level, it opens the circuit and shuts the motor down,
preventing over-pressurization, overheating, and dry-running that would otherwise shorten component life.

Stable, consistent system behavior

This automatic cycling smooths pressure delivery at the spray tool, reducing saw-toothing and water hammer so
operators experience steadier trigger feel, cleaner spray patterns, and less fatigue during long passes.
Calmer hydraulics at the pump also help extend seal, bearing, and valve service intervals while supporting
predictable downstream chemical draw when injectors are in use.

Construction & Durability

The AL692 is built from corrosion-resistant materials for long service in wet, detergent-rich environments.
A solid brass housing provides excellent dimensional stability and heat dissipation, while reinforced internal
polymers resist fatigue across thousands of cycles in residential, commercial, and light industrial equipment.
Moisture-shielded contacts protect against spray, dust, and detergent mist, minimizing the risk of oxidation or
false signals and keeping switching accuracy intact between maintenance checks.

Connection & Integration

Featuring a 1/4″ male threaded connection, the AL692 seats securely into standard ports on
pump heads, manifolds, and compact control blocks. The fixed, non-swivel body preserves alignment, forming a
tight, leak-resistant interface that maintains line integrity under vibration and thermal swings and prevents
the micro-movement that can cause weeping at joints over time.

The compact form factor simplifies placement in tight housings, mobile rigs, and wall-mount stations where
space is at a premium. Clean, finely cut threads engage easily for quick installation with common tools, making
the switch suitable for both new builds and retrofits on legacy equipment.

Installation & Commissioning

Commissioning the AL692 is straightforward:

• Install the 1/4″ male thread into the designated port, ensuring sealing faces and threads are clean.
• Snug to the recommended torque to compress the seal without over-tightening.
• Run a brief test cycle, observing gauge behavior and confirming that the switch closes on low pressure and opens at the target cut-out.
• Verify that the pump starts and stops predictably in response to trigger pulls or flow changes downstream.

In daily operation the AL692 acts as a safeguard, keeping pumps from running when tools are idle or water
supply is disrupted, lowering energy use and reducing heat build-up in the drive end.

Maintenance & Troubleshooting

Routine care is minimal: include the switch in visual inspections, confirming that the brass body remains tight,
threads are clean, and the sensing path is free of debris so response time stays crisp. Because the AL692’s
behavior is repeatable, it also serves as a useful diagnostic reference—if cycling becomes erratic, technicians
can quickly verify cut-in and cut-out performance and then focus on upstream fouling, unloader settings, or
nozzle wear if the switch checks out.

Typical Applications

• Electric and gas pressure washers.
• Compact wash stations and wall-mount bay systems.
• Mobile cleaning rigs and service-vehicle installations.
• Sprayers and other equipment requiring automatic pressure-based pump control.

AL692 Mini Pressure Switch | 1/4 in Male, Compact AL Series

• Mini pressure switch from the Annovi Reverberi AL Series for automatic on/off control.
• Precision diaphragm and spring assembly for accurate cut-in/cut-out response.
• Rugged brass housing with corrosion-resistant internal materials.
• 1/4″ male threaded connection for broad compatibility with pump heads and manifolds.
• Sealed electrical contacts for reliable operation in wet, detergent-rich environments.
• Compact, installer-friendly form factor ideal for tight housings and mobile rigs.
• Helps reduce energy consumption, protect pumps, and extend overall system life.
