TPR255-07 Rotating Nozzle | 3700 PSI Turbo Cleaner

TPR255-07 Rotating Nozzle | 3700 PSI Turbo Cleaner

The AR North America TPR255-07 Rotary Turbo Nozzle is a high-capacity, heavy-duty rotating
nozzle engineered for large-scale commercial and industrial pressure washing operations. Featuring a
large 7.0 orifice size and a standard 1/4-inch female inlet, this nozzle is
designed to deliver maximum water volume while maintaining strong, consistent cleaning impact. With a
maximum pressure rating of 3,700 PSI and compatibility with hot-water systems, the
TPR255-07 is well suited for demanding environments where productivity, durability, and deep cleaning
power are essential.

Built on the proven TPR255 “255-series” platform, the TPR255-07 combines rugged brass construction with
robust internal components that are designed to withstand continuous operation under load. This makes
it an excellent choice for contractors, fleet operators, agricultural facilities, municipalities, and
industrial maintenance teams that rely on high-flow pressure washer systems to clean large surfaces and
remove heavy buildup efficiently. Compared to smaller orifice turbo nozzles, the TPR255-07 emphasizes
coverage and throughput, allowing operators to clean more area in less time.

The large orifice allows significantly more water to pass through the nozzle, which is especially
beneficial when paired with high-GPM pressure washers. This higher flow drives the internal rotor at a
stable speed, producing a powerful rotating jet that delivers consistent impact across a wide cleaning
path. The result is faster removal of grease, oil, thick mud, caked dirt, mineral deposits, and other
stubborn contaminants commonly found in industrial and agricultural settings.

Key Specifications

• Model: TPR255-07 Rotary Turbo Nozzle
• Nozzle Orifice Size: 7.0 (high-flow configuration)
• Maximum Operating Pressure: 3,700 PSI (255 bar)
• Inlet Connection: 1/4-inch female (1/4″ F)
• Maximum Water Temperature: Approximately 210–212°F (hot-water capable)
• Spray Pattern: Rotating zero-degree jet forming a dynamic rotary cone
• Construction: Brass body with heavy-duty internal rotor and wear-resistant components
• Application Class: Commercial and industrial heavy-duty cleaning

How the TPR255-07 Works

The TPR255-07 uses a rotating jet design to transform concentrated water pressure into a highly effective
cleaning action. When pressurized water enters the nozzle, it flows through the 7.0-size
orifice, allowing a large volume of water to reach the internal jet assembly. This water flow
drives a precision-balanced rotor that spins rapidly under pressure.

• As the rotor spins, it converts a single zero-degree jet into a fast-rotating cone of water,
  delivering repeated high-impact strikes across a circular cleaning path.
• The rotating pattern spreads cleaning energy over a wider area than a fixed straight jet, reducing
  streaking and allowing for more uniform results on large surfaces.
• High flow combined with rotation makes the nozzle particularly effective at removing thick,
  stubborn buildup rather than just surface-level dirt.
• Proper matching of the nozzle’s orifice size to the pressure washer’s GPM and PSI ensures stable
  rotor speed, consistent impact, and long service life.

Because the TPR255-07 prioritizes flow and coverage, it excels in applications where speed and efficiency
matter more than ultra-fine precision. It is designed to reduce the number of passes required to achieve
a clean surface, saving both time and operator effort on large jobs.

Typical Applications

The aggressive cleaning capability and wide coverage of the TPR255-07 make it suitable for a wide range
of heavy-duty pressure washing tasks on durable surfaces.

• Large concrete slab and facility floor cleaning: Warehouses, loading docks,
  industrial yards, parking lots, fueling pads, and large exterior slabs where oil, grease, tire
  marks, and industrial residue accumulate.
• Heavy equipment and fleet washdown: Construction equipment, farm machinery,
  trailers, dump trucks, and fleet vehicles with caked mud, clay, grease, and road film.
• Industrial and municipal maintenance: Factories, plants, municipal yards, wash
  bays, maintenance areas, and service facilities that require frequent, high-volume cleaning.
• Concrete repair preparation and surface cleaning: Removing loose coatings,
  flaking paint, scale, and contaminants prior to sealing, coating, painting, or resurfacing.
• Agricultural and heavy-duty wash areas: Barn floors, feedlot pads, livestock
  yards, and farm facilities where dirt, manure, mud, and organic buildup must be removed quickly
  and thoroughly.

Sizing and Compatibility Recommendations

Correct sizing and system compatibility are essential for safe operation and optimal performance when
using a high-flow turbo nozzle like the TPR255-07.

• The 7.0 orifice size is best paired with high-flow commercial or industrial pressure
  washers. Many residential or small electric units do not supply sufficient GPM to maintain proper
  rotor speed.
• Always verify the pressure washer’s maximum PSI and GPM output before installation
  to ensure the nozzle operates within its design limits.
• The standard 1/4-inch female inlet allows easy connection to most professional spray guns, lances,
  and quick-connect couplers.
• For hot-water operation, confirm that all hoses, guns, and fittings in the system are rated for
  temperatures up to 212°F.
• Due to its aggressive rotating action, the TPR255-07 is not recommended for delicate materials such
  as wood, painted siding, soft plastics, or thin metal without careful testing.

Maintenance and Best Practices

Following proper maintenance and operating practices will help extend the life of the TPR255-07 and
maintain consistent cleaning performance.

• Flush water supply lines thoroughly before installing the nozzle to remove grit, sand, or debris
  that could damage internal components.
• At startup, point the nozzle at a durable surface to allow the rotor to spin up smoothly before
  moving into close-range cleaning.
• Maintain an appropriate working distance during cleaning to avoid surface damage or reduced
  effectiveness.
• Inspect the nozzle regularly for uneven spray patterns, reduced rotation, leaks, or visible wear.
• For high-use operations, keeping spare internal components or replacement nozzles on hand can help
  minimize downtime and maintain productivity.

The TPR255-07 Rotating Turbo Nozzle is a powerful, high-flow solution for professionals
who need to clean large, heavily contaminated surfaces efficiently. With its durable construction,
hot-water capability, and wide cleaning footprint, it is an excellent choice for industrial,
municipal, agricultural, and heavy-equipment pressure washing applications.
