RMV25G30D-PKG | 2.5 GPM 3000 PSI Universal Pressure Pump Package

RMV25G30D-PKG by Annovi Reverberi — Complete RMV Series Axial Radial Pump Package | 2.5 GPM | 3,000 PSI | Forged Brass Manifold | F7 3/4″ Shaft | Fixed 12% Injector | Thermal Relief | 22mm Outlet | 7,500 Cleaning Units

The RMV25G30D-PKG by Annovi Reverberi is a complete, installation-ready RMV Series axial radial pump package engineered for direct drive gas engine-powered pressure washing systems requiring 2.5 GPM at 3,000 PSI from a compact, fully rebuildable platform. Rated at 2.5 GPM and 3,000 PSI, the RMV25G30D-PKG delivers 7,500 cleaning units — through a forged brass manifold, ceramic pistons, a fixed 12% chemical injector, thermal relief protection, and a 3/4″ hollow F7 shaft for direct coupling to compatible 5–7 HP gasoline engines — all in one organized, factory-assembled box. The RMV25G30D-PKG is the standard direct-drive version of the RMV25G30D platform — without Easy Start, at the universal specification for operators replacing pumps on existing 5–7 HP machines. Backed by AR North America’s nationwide service and parts network. Protected by a 2-year US limited warranty. Fully rebuildable. As part of Annovi Reverberi’s pump package lineup stocked and supported by WSHPWR, the RMV25G30D-PKG is the complete 3,000 PSI forged brass solution for residential, contractor, and agricultural operators who buy right the first time.

Everything in One Box — The RMV25G30D-PKG Complete Package Contents

Forged Brass Manifold. 3,000 PSI. Factory-Assembled. Nothing Left to Source.

• RMV25G30D axial radial pump with forged brass manifold — factory-assembled and ready to mount. At 3,000 PSI, the forged brass manifold is the correct material specification — pressure cycling stability, corrosion resistance, and thermal durability for sustained residential and contractor duty cycles. Ceramic pistons, aluminum connecting rods. 3/4″ hollow F7 shaft for direct 5–7 HP gasoline engine coupling at 3,400 RPM. 7.5 lbs.
• Fixed 12% chemical injector — integrated into the pump assembly. Connect the chemical tube and insert the chemical filter into the detergent container — the system draws chemical automatically at the correct 12% draw rate. No separate injector to source or install.
• Chemical tube and chemical filter — complete downstream detergent delivery assembly. Flush with clean water after every chemical use.
• Easy-grip swivel type garden hose adapter — swivel design for tool-free hookup to standard garden hose supply lines without twisting the inlet connection.
• Stainless steel filter screen — protects the forged brass manifold, ceramic pistons, and injector from supply water sediment and particulate.
• Thermal relief protection valve — auto-activates during extended bypass, vents hot water, draws cooler supply water. Auto-resets when temperature normalizes.
• Hex Allen style low-profile fasteners with locking washers — vibration-resistant engine-to-pump mounting hardware for secure installation.
• 22mm outlet threads — universal pressure washer hose connection. No adapters at the outlet.
• Operations manual with parts schematic — complete installation, operating, maintenance, and rebuild procedures. Every AR North America part number for every serviceable component.

Decoding the RMV25G30D-PKG

What This Annovi Reverberi Designation Tells You

• RMV — Pump series: RMV Series axial radial pump — Annovi Reverberi’s professional replacement pump platform
• 25G — Pump series identifier for this RMV configuration
• 30 — Maximum pressure: 3,000 PSI — 2.5 × 3,000 = 7,500 cleaning units
• D — Shaft version: Direct drive — 3/4″ hollow keyway F7 shaft for 5–7 HP gas engine coupling
• PKG — Complete package: forged brass manifold pump, 12% injector, chemical tube and filter, swivel GHA, stainless filter screen, thermal relief valve, hex Allen locking fasteners, 22mm outlet, and operations manual with parts schematic

RMV25G30D Family — PKG vs EZ-PKG

Both models share the RMV25G30D forged brass manifold platform, 3,000 PSI rating, fixed 12% injector, and F7 3/4″ shaft:

• RMV25G30D-PKG (this model) — Standard direct-drive package without Easy Start. The correct specification for replacing a pump on a machine that already has an internal bypass management system, or where Easy Start is not a requirement.
• RMV25G30D-EZ-PKG — Adds Easy Start (EZ) zero-back-pressure startup. The bypass circuit opens at startup — the engine engages freely against zero hydraulic resistance. The correct specification when the engine is paired with a worn recoil starter, when cold-weather starts are a concern, or when the operator simply wants the easiest startup experience every time.

Key Specifications

RMV25G30D-PKG Technical Details at a Glance

• Flow Rate: 2.5 GPM (gallons per minute)
• Maximum Pressure: 3,000 PSI
• Cleaning Units: 7,500 (GPM × PSI)
• Operating Speed: 3,400 RPM — direct drive gas engine
• Power Required: 5.1 EBHP minimum
• Pump Type: RMV Series axial radial — wobble plate design, fully rebuildable
• Manifold: Forged brass — correct specification at 3,000 PSI
• Pistons: Ceramic
• Connecting Rods: Aluminum — frictionless design
• Bore Diameter: 12mm / Stroke: 9.7mm
• Shaft: D — 3/4″ hollow keyway, F7 SAE J609a flange, direct drive 5–7 HP gas engine
• Outlet: 22mm threads — universal pressure washer hose connection
• Max Temperature: 140°F
• Oil Capacity: 2.2 oz
• Weight: 7.5 lbs
• Easy Start: Not included — standard direct drive configuration
• Chemical Injector: Fixed 12% — integrated
• Thermal Relief: Included — auto-activates and auto-resets
• Inlet Adapter: Easy-grip swivel type garden hose adapter
• Filtration: Stainless steel filter screen
• Fasteners: Hex Allen low-profile with locking washers
• Serviceability: Fully rebuildable — all components nationally available through AR North America
• Warranty: 2-year limited warranty — US-based coverage through Annovi Reverberi North America

Engine Compatibility — What Drives the RMV25G30D-PKG

F7 SAE J609a. 3/4″ Hollow Shaft. 5.1 EBHP Minimum. Direct Bolt-On.

• Harbor Freight Predator 224cc / 6.6 HP Max Performance — the preferred Predator pairing for the RMV25G30D-PKG. Up to 10% more torque than the 212cc — best overhead for sustained 3,000 PSI operation. 3/4″ keyway shaft.
• Harbor Freight Predator 212cc / 6.5 HP — 3/4″ keyway shaft. 6.5 HP — above the 5.1 EBHP minimum. Compatible for residential and contractor builds.
• Honda GX200 / 5.5 HP — 196cc, 3/4″ keyway shaft. 5.5 HP — marginally above the 5.1 EBHP minimum. Suitable for residential duty cycles. The Predator 212cc or 224cc provides better sustained overhead.
• Briggs & Stratton XR950 — 3/4″ keyway shaft. Compatible for residential and light contractor builds.
• Kohler CH270 / Command series — 3/4″ keyway shaft. Compatible for applicable small-frame configurations.

The RMV25G30D-PKG Difference — Engineered to Be Rebuilt, Not Replaced

• Fully rebuildable — every wear component in the RMV25G30D-PKG — forged brass manifold seals, ceramic pistons, chemical injector, thermal relief valve, stainless filter screen — is individually available through AR North America’s nationwide distribution. When service is eventually required, the parts are there. Rebuild it. Keep running.
• Nationwide AR North America service centers — authorized service centers across North America stock RMV Series parts and provide technical support. Local professional service is available when needed.
• Upgrade your results with the right nozzle — at 3,000 PSI and 2.5 GPM, nozzle selection directly drives cleaning performance on every surface. Explore WSHPWR’s complete selection of spray nozzles and rotating heads to get the full performance from this pump package.

RMV25G30D-PKG Typical Applications

• Residential cleaning — driveways, siding, decks, patios, fences, and vehicles — forged brass 3,000 PSI performance with integrated 12% chemical delivery for residential users who want a rebuildable professional-platform pump
• Contractor mobile wash rigs and property maintenance — direct bolt-on replacement for worn 3,000 PSI pumps on existing 5–7 HP machines; complete kit format eliminates sourcing delays
• Agricultural equipment rinse-down and barn cleanup — forged brass manifold durability and stainless filtration for agricultural operating conditions
• Facilities and municipalities — service bays and public space maintenance — rebuildable, standardized packages with nationwide service support

2-Year US Warranty, Nationwide Service Centers, and Wholesale Pricing

Engineered for Professional Pressure Washing. Backed Across North America. Rebuildable.

The RMV25G30D-PKG is protected by Annovi Reverberi’s 2-year limited warranty through the US-based warranty and service network administered by AR North America. Every wear component is stocked nationally through authorized AR North America service centers and distribution channels. Contractors, residential users, agricultural operations, OEM builders, resellers, and volume buyers are invited to contact the WSHPWR wholesale team for pricing on the RMV25G30D-PKG and the complete WSHPWR pump package lineup.

7,500 Cleaning Units. 3,000 PSI. 2.5 GPM. Forged Brass Manifold. Fixed 12% Injector. 22mm Outlet. F7 3/4″ Shaft. Everything in One Box.

Annovi Reverberi RMV Series. Fully Rebuildable. Nationwide Service. 2-Year US Warranty.

The RMV25G30D-PKG is the forged brass 3,000 PSI pump for operators who buy right the first time — a rebuildable, professionally engineered axial radial pump package with integrated chemical delivery, thermal protection, and AR North America nationwide service support. Forged brass manifold. Ceramic pistons. Fixed 12% integrated injector. Swivel garden hose adapter. Stainless filter screen. Thermal relief valve. Hex Allen locking fasteners. 22mm outlet. Operations manual with parts schematic. Two-year US warranty. Nationwide service centers. 7.5 lbs. Fully rebuildable.

Volume buyers and contractors can reach the WSHPWR wholesale team directly at wholesale@wshpwr.com to discuss pricing across the complete Annovi Reverberi pump package lineup.
