MVR20018 Adjustable Injector 1.8 mm | 4060 PSI Chem

MVR20018 Adjustable Chemical Injector (1.8 mm, 4,060 PSI)

• Adjustable Venturi chemical injector engineered for controlled detergent draw and operator-managed dilution in professional pressure washing systems.
• Configured with a 1.8 mm orifice and rated to 4,060 PSI for commercial equipment where dependable chemical delivery and repeatable tuning are required.
• Designed for approximately 2.5–5.5 GPM systems that need stable suction performance while allowing technicians to fine-tune chemical strength for different surfaces and soil loads.
• Supports wash programs that change frequently—pre-soak, detergent wash, and rinse—without requiring injector swaps or fixed-ratio limitations.

MVR20018 Chemical Injection Method

Venturi-Based Draw with Adjustable Metering

• Uses a Venturi restriction to create a controlled low-pressure zone that draws detergent from a container into the water stream during low-pressure chemical mode.
• Integrated metering control allows the operator to regulate chemical concentration in real time, improving flexibility across mixed workloads.
• Balanced suction strength supports longer hose runs and common field configurations, including elevated hose reels and frequent trigger cycling.
• Adjustment capability supports consistent results across varied detergents, including soaps, general-purpose cleaners, and compatible degreasers that behave differently under suction.

Application Control for Job-to-Job Consistency

• Adjustable design supports standardized procedures by allowing crews to set a preferred range for specific tasks and repeat it across service calls.
• Improves process control where multiple surfaces and contamination types are encountered in the same shift.
• Supports predictable wetting and dwell behavior by enabling the operator to match concentration to ambient conditions, surface temperature, and soil load.
• Reduces rework by allowing fast correction if foam is too light, dwell is too short, or chemical strength is excessive for the substrate.

System Integration and Performance

MVR20018 Flow Range Compatibility and Pressure Management

• Optimized for roughly 2.5–5.5 GPM systems where injector sizing influences suction strength and pressure drop behavior.
• Designed to minimize unnecessary pressure loss so the system maintains usable performance during rinse cycles and transitions cleanly between soap and high-pressure operation.
• Best performance is achieved when installed in the correct location in the discharge circuit and paired with low-pressure soap tips that enable stable Venturi suction.
• Stable draw characteristics support consistent chemical pickup across long discharge hose runs typical of fleet and facility cleaning.

Backflow Protection and Chemical Line Control MVR20018

• Integrated check valve prevents reverse flow into the chemical line, protecting detergent containers from contamination and unintended dilution.
• Reduces the risk of chemical container pressurization during shutdown or rapid pressure changes.
• Helps maintain prime and responsiveness when switching back into chemical mode after rinsing.
• Supports cleaner operation by reducing migration of water into the suction hose when the injector is not actively drawing.

Construction and Durability

Materials Selected for Chemical Exposure

• Durable brass housing provides strength and corrosion resistance for daily handling, vibration, and continuous-duty service.
• Stainless-steel internal components resist wear and corrosion in detergent and degreaser environments common to professional cleaning programs.
• Precision-machined Venturi passages reduce turbulence and support efficient hydraulic behavior, helping preserve pump efficiency and outlet pressure.
• Compact inline form factor supports clean integration on skids, carts, and wall mounts without requiring excessive plumbing complexity.

MVR20018 Installation Details That Reduce Errors

• Inline body is intended to install downstream of the pump in the discharge circuit where chemical injection is typically managed during low-pressure operation.
• Standard threaded or quick-connect compatibility supports rapid service replacement and consistent fleet builds.
• Compact footprint fits crowded manifolds and tight frame rails while maintaining reasonable access to the adjustment control.
• Orientation control and clean hose routing improve troubleshooting efficiency and reduce air leaks that can interrupt draw.

Operation and Maintenance

Operating Practices for Stable Draw

• Chemical draw is typically engaged using a low-pressure soap nozzle; switching to a high-pressure tip generally stops draw by increasing backpressure.
• Best results are achieved when the detergent container is vented, positioned close to the injector, and connected with an unrestricted suction hose.
• Stable draw depends on airtight suction connections, a clean intake screen, and eliminating kinks or restrictions that reduce suction flow.
• Metering adjustments should be made gradually to maintain consistent foam and predictable dwell, especially when changing detergent types.

Routine Maintenance Guidelines

• Flush clean water through the injector and suction line after detergent use to prevent residue buildup and check-valve sticking.
• Inspect the intake screen, suction tubing, and fittings routinely for debris, softening, or air leaks that can interrupt draw.
• Replace aged suction hose and strainers proactively in high-use environments to maintain repeatable performance and minimize downtime.
• Keep chemical containers free of sediment to protect internal sealing surfaces and maintain consistent suction performance.

MVR20018 Technical Specifications

• Model: MVR20018
• Type: Adjustable Venturi chemical injector with metering control
• Orifice: 1.8 mm
• Maximum Pressure: 4,060 PSI
• Recommended System Range: Approximately 2.5–5.5 GPM (application dependent)
• Body Material: Brass
• Internal Components: Stainless steel
• Protection: Integrated check valve for backflow prevention

Typical Industrial and Commercial Applications

• MVR20018 Fleet washing and vehicle maintenance where adjustable concentration supports changing soil loads and seasonal conditions.
• Equipment bays and agricultural facilities using 2.5–5.5 GPM machines that require repeatable but adjustable downstream injection.
• Commercial property cleaning where operators need to tune detergent strength for concrete, siding, loading areas, and general washdown.
• Mobile wash rigs and contractor fleets that benefit from one injector adaptable to multiple detergents and job types.
• Wash bays and skid systems where stable draw across longer hose runs improves uptime and reduces troubleshooting.
