BIXC060E400 Bolondi Electric Tank Head | 400 Bar

BIXC060E400 – Bolondi Electric Rotary Cleaning Head – Stainless Steel, Rated 400 Bar

The Bolondi BIXC060E400 is an ultra high-pressure electric rotary cleaning head engineered for the most demanding industrial and sanitary cleaning tasks. With a maximum working pressure of 400 bar (~5,800 PSI) and a flow rate up to 60 L/min (≈16 GPM), it delivers extreme cleaning power for tanks, IBCs, reactors, silos, and process vessels where standard CIP tools fall short.

Constructed from AISI 316 stainless steel, the unit resists corrosion, aggressive chemicals, and high-temperature cleaning cycles—ideal for food processing, chemicals, pharmaceuticals, coatings, adhesives, and bulk storage applications.

Electric Drive for Controlled Precision

• Constant Rotation Speed – Electric drive maintains steady rotation regardless of flow or pressure changes.
• Uniform Coverage – Gear-driven motion ensures consistent 360° internal cleaning.
• Shorter Cleaning Cycles – Efficient jet motion reduces wash times and increases throughput.
• High Reliability – Electric motor avoids stalling under variable operating conditions.

These benefits make the BIXC060E400 ideal for CIP systems requiring validated, repeatable performance.

Extreme Cleaning Performance

At 5,800 PSI, the BIXC060E400 generates enough mechanical impact to remove severe residues, including:

• Chemical crusts inside reactors and vessels
• Cured adhesives, resins, and coatings
• Burned-on sugars, proteins, or starches
• Grease, scale, and mineral buildup
• Pharmaceutical residues requiring validated removal

Equipped with 2–4 high-performance nozzles, the rotary arms deliver powerful spiral-pattern jetting that eliminates dead zones, even in large or irregular tanks.

BIXC060E400 Stainless Steel Engineering

• Superior corrosion resistance against acids, caustics, and detergents
• Sanitary finish suitable for food and pharmaceutical applications
• Strength under extreme operating pressure and temperature
• Long-lasting performance in abrasive or chemical-heavy environments

Integrated Filtration

The system includes an internal debris filter that traps particles before they can reach the motor or nozzles—reducing clogging, preventing downtime, and extending equipment life.

How It Works

• Connection: Installed directly into a high-pressure CIP line and connected to power.
• Motor Drive: Electric motor activates precision gear assembly.
• Fluid Jetting: High-pressure cleaning solution exits through 2–4 nozzles.
• Full Coverage: Arms rotate in a continuous spiral pattern for complete interior cleaning.
• Residue Removal: High-impact jets strip away deposits, scale, and hardened material.

BIXC060E400 – Bolondi Electric Rotary Cleaning Head – Stainless Steel, Rated 400 Bar

Features & Specifications

• Pressure Capacity: Up to 400 bar (~5,800 PSI)
• Flow Rate: Up to 60 L/min (≈16 GPM)
• Drive System: Electric motor with precision gears
• Spray Pattern: Uniform 360° spiraling jet coverage
• Nozzle Options: 2–4 high-efficiency nozzles
• Filtration: Integrated debris filter
• Material: AISI 316 stainless steel

BIXC060E400 Built-to-Order Production

• Air Freight: ~8 weeks
• Sea Freight: ~14 weeks

Each unit is built to order in Italy and configured specifically for the customer’s cleaning system.

Why Choose the BIXC060E400?

For facilities where downtime is costly and residues are severe, the Bolondi BIXC060E400 offers unmatched cleaning force, electrically controlled precision, and long-term stainless steel durability. It is the premier choice for demanding CIP applications requiring validated, repeatable, and high-impact cleaning performance.
